TALIN Inertial Land Navigator Family
Overview
Honeywell’s Tactical Advanced Land Inertial Navigator (TALIN) utilizes our industry-leading GG1320 digital ring laser gyro and Q-Flex accelerometers to provide customers with highly durable, precise and reliable inertial navigation systems. TALINs are easily installed and can be mounted in any orientation, which provides customers with an inertial navigation system that is smaller, lighter and more reliable than other competing products.TALIN inertial navigation systems are proven, battle-tested and are used in a variety of different applications with more than 16,000 TALIN systems in the air, on land and at sea across 60 commercial and military platforms worldwide.Whether you’re looking for our best-in-class TALIN 6000 or a cost-effective TALIN 1000, our performance levels are configurable to meet a variety of commercial and military needs that have different compatibility requirements.
Compatible Platform
Armored Vehicles
Artillery application
Construction, Geological Survey, Maritime, Mining, Oil and Gas
Military light to medium vehicles
Radar/satcom stabilization, missile launcher pointing/stabilization
Secondary Safety Navigation System for Indirect Fire
Specifications
Physical
Weight
- ~13 lbs(6kg)*
Dimensions
- Approx. 14 H x 19 W x 22 L cm
- Approx. 5.4 H x 7.6 W x 8.6 L in
- Approx. 5.4 H x 7.6 W x 8.6 L inches
Maintenance
Mean Time Between Failures (MTBF)
- >50,000 hours (TALIN demonstrated)
Mechanical
Operating Temperature
- No cooling required: -46°C to 71°C (-51°F to 160°F)
Filter
Power and Electrical
Power Consumption
- 18-32Vdc: <26 watts
Performance
Key Benefits
- Can be hard mounted in any orientation
- Cost-effective system
- Light, small and power efficient
- TALIN 500 and TALIN 2000 systems are designed specifically to meet the needs of light vehicle operators at a lower price point
- TALIN technology is being used to improve efficiency and safety in mining, manufacturing, robotics and other industries.
Industry
- Defense
- Engineering, Test and Measurement
- Federal Solutions
- Geospatial and Atmospheric
- Ground Transportation and Logistics
- Mining
Connectivity and Systems
Software
- Dynamic Point-on-TheMove capability – Provides first-strike capability
- Field upgradable
- Modular- partitioned for cost-effective system missionisation
- Works even in GPS denied environments
