Traffic Awareness
MILACAS-XR
The MILACAS-XR is available in both a 6 modular concept unit (MCU) and 4 MCU model.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
The MILACAS-XR is available in both a 6 modular concept unit (MCU) and 4 MCU model. MILACAS-XR provides double the surveillance range than ETCAS, utilizing improved interrogation methods and hybrid surveillance (automatic dependent surveillance broadcast - ADS-B).
MILACAS-XR (Extended Range) provides two times the surveillance range of ETCAS. Utilizing improved interrogation methods and Hybrid Surveillance (Automatic Dependant Surveillance Broadcast - ADS-B). MILACAS-XR surveillance range is 100 nm for 360° azimuth. The system is approved by civil and military frequency management organizations, including the U.S. National Telecommunications and Information Administration for installation on all military aircraft. In addition to the increased range, MILACAS-XR provides the same functions that have made ETCAS the largest selling military TCAS product in the world.
MILACAS-XR (Extended Range) provides two times the surveillance range of ETCAS. Utilizing improved interrogation methods and Hybrid Surveillance (Automatic Dependant Surveillance Broadcast - ADS-B). MILACAS-XR surveillance range is 100 nm for 360° azimuth. The system is approved by civil and military frequency management organizations, including the U.S. National Telecommunications and Information Administration for installation on all military aircraft. In addition to the increased range, MILACAS-XR provides the same functions that have made ETCAS the largest selling military TCAS product in the world.
Specifications
Physical
- Weight
- 4 MCU: 12.0 lbs
- 6 MCU: 12.5 lbs
- Dimensions
- 4 MCU: 7.62 x 4.90 x 15.02 in.
- 6 MCU: 7.62 x 7.50 x 15.02 in.
Environmental
- Environmental Requirement
- Per DO-160D
Power and Electrical
- Power Input Required
- 50 W nominal, 60 W maximum
- Transmit Frequency
- 1030 MHz
- Power Requirement
- 115 Vac and/or 28 Vdc
- Power Dissipation
- 50 W maximum
Filter
- Compatible Platform
- Alenia C-27J
- Bell Boeing V-22
- CN-295 Military Aircraft
- Kawasaki C-X & P-X
- Lockheed Martin C-130J
- Lockheed Martin VH-71
Performance
- Receiver Frequency
- 1090 MHz
- Temperature range
- Non-Operating -55 C to +85 C
- Operating -55 C to +70 C
- Key Benefits
- Drop-in Replacement
- Increased surveillance range to 100 nautical miles for 360° azimuth
- Integrates MOPS Change 7.1 Technologies
- Cooling
- Recommended but not required
Connectivity and Systems
- Software Loading
- PCMCIA, ARINC 615, Ethernet
- Interfaces
- Per ARINC 735A
Certification
- Certifications
- TSO C119b
Maintenance
- Replaces
- TPA-81A
Mechanical
- Mounting
- Mounting Tray (ARINC 600)
Physical
- Weight
- 4 MCU: 12.0 lbs
- 6 MCU: 12.5 lbs
- Dimensions
- 4 MCU: 7.62 x 4.90 x 15.02 in.
- 6 MCU: 7.62 x 7.50 x 15.02 in.
Environmental
- Environmental Requirement
- Per DO-160D
Power and Electrical
- Power Input Required
- 50 W nominal, 60 W maximum
- Transmit Frequency
- 1030 MHz
- Power Requirement
- 115 Vac and/or 28 Vdc
- Power Dissipation
- 50 W maximum
Filter
- Compatible Platform
- Alenia C-27J
- Bell Boeing V-22
- CN-295 Military Aircraft
- Kawasaki C-X & P-X
- Lockheed Martin C-130J
- Lockheed Martin VH-71
Performance
- Receiver Frequency
- 1090 MHz
- Temperature range
- Non-Operating -55 C to +85 C
- Operating -55 C to +70 C
- Key Benefits
- Drop-in Replacement
- Increased surveillance range to 100 nautical miles for 360° azimuth
- Integrates MOPS Change 7.1 Technologies
- Cooling
- Recommended but not required
Connectivity and Systems
- Software Loading
- PCMCIA, ARINC 615, Ethernet
- Interfaces
- Per ARINC 735A
Certification
- Certifications
- TSO C119b
Maintenance
- Replaces
- TPA-81A
Mechanical
- Mounting
- Mounting Tray (ARINC 600)
- Weight : 4 MCU: 12.0 lbs|6 MCU: 12.5 lbs
- Environmental Requirement : Per DO-160D
- Power Input Required : 50 W nominal, 60 W maximum
- Compatible Platform : Alenia C-27J|Bell Boeing V-22|CN-295 Military Aircraft|Kawasaki C-X & P-X|Lockheed Martin C-130J|Lockheed Martin VH-71
- Transmit Frequency : 1030 MHz
- Receiver Frequency : 1090 MHz
- Temperature range : Non-Operating -55 C to +85 C|Operating -55 C to +70 C
- Power Requirement : 115 Vac and/or 28 Vdc
- Power Dissipation : 50 W maximum
- Software Loading : PCMCIA, ARINC 615, Ethernet
- Certifications : TSO C119b
- Key Benefits : Drop-in Replacement|Increased surveillance range to 100 nautical miles for 360° azimuth|Integrates MOPS Change 7.1 Technologies
- Interfaces : Per ARINC 735A
- Dimensions : 4 MCU: 7.62 x 4.90 x 15.02 in.|6 MCU: 7.62 x 7.50 x 15.02 in.
- Replaces : TPA-81A
- Mounting : Mounting Tray (ARINC 600)
- Cooling : Recommended but not required
